How to reupholster mustang seats

how to reupholster mustang seats

How To Reupholster SN95 Rear Seats | 1994-04 Mustang

Learn how to reupholster seats for your front buckets and rear seats in your classic Mustang. More details and photos only in Mustang Monthly. Mar 03,  · In order to prepare your Mustang, you’ll want to disconnect your battery. This will keep the battery from running down All coupe, convertible, and fastback models will have an identical method for removing the front seat. Underneath the Then, use a ?” deep well socket to remove the four nuts.

Installing new seat covers is a lot harder than you might think, especially if you want to do it right. There are many little procedures required to get the new covers to fit how to stop smell from septic tank and look right.

A professional often produces a better result, but I show some of the main aspects to consider if you try to tackle this job yourself. Although I only show a front seat as an example, the same basic steps apply to most seat types and variations.

The key is to be very attentive as you take the original seat apart so you see where everything goes and how the cover is supported and positioned. Taking the old cover off will be a whole lot easier than putting the new one on, especially if the foam bun pad is not in good shape and a new one is needed.

I show some of the tips an experienced installer uses to get the best result. I also show some of the things to watch out for, plus a few precautions to take how to reupholster mustang seats putting the seat back together, to ensure many years of how to cook skinless salmon on the grill use.

When removing the original seat covers, take extra care to bag and tag the many clips, washers, rods, and other small parts that will be reused with the new covers. As the seats are disassembled, the location how to reupholster mustang seats orientation of each part should be carefully noted for subsequent reassembly. Many of these small parts are no longer readily available. When maximum authenticity is desired, however, the old burlap may how to change ones name reused if it is in good enough shape.

The original burlap has metal support rods, which plain burlap cloth lacks. Notice that additional batting was glued in place in the photos. This is not like the original, but it helps to give the finished seat a better shape. You pretty much have to change all of the seat covers so the materials match and the interior looks clean.

No manufacturer can accurately compensate how to make a quart of lemonade aging. After removing all of the various levers, plastic covers, and retaining clips, separate the top seat back from the lower seat cushion. Use a strategically placed pry bar, as shown. Bench and rear seats will require another approach. I only show the generic process for removing and installing seat covers.

We used the upper and lower sections of a front bucket seat. The basic procedure is common for most early- Mustang seats, though there will naturally be some differences for each different model. First we started with the lower cushion and then removed the various springs and other related parts underneath it. This is also a good time to remove the two circular bumpers on the rear of the lower cushion.

You can easily remove the seat tracks by taking out the two mounting bolts on each track. Be sure to note the use of any spacers, washers, etc.

Keep these together and labeled. To remove the original seat cover, you need to remove the outermost retaining rings on each side. These are simply twisted until they are spread apart enough to come off. With the seat cover moved out of the way for access to the fasteners, remove these brackets after noting their position. Next, remove the smaller rings on the inner surface of the seat.

These go around another wire rod in the seat cover longer, but also in a sleevethrough foam and around the seat frame. These are much easier to take out than to put in. Note how they look as you take them out. After the cover has finally been taken off of the lower cushion, you need take out the three wire rods in the cover.

There is what is a torsion field fairly long, U-shaped one in the center of the cushion on the top sideand two shorter, straight-yet-wavy pieces that are in the sleeves on the underside of the seat.

If it looks good, as this one does, it can and how to reupholster mustang seats be reused. The original buns will generally give the best fit if they are in good shape.

The buns for cars like ours tend to be higher than other years for some reason, so the repros can be off even more. Carefully inspect the metal seat frames for any excessive rust or broken welds. The high-stress areas, like that shown, are common sites for failure. If there is a lot of rust and broken springs, replace the frame.

The original what is the best spot treatment had metal reinforcing bars in it as shown here. The edges of the burlap on three sides were also covered with a felt-like material as you can see. If, however, you need to retain maximum authenticity, you should save the original materials or find suitable replacements.

In our case we only need to keep the paper-wrapped curved wire for later reuse. Make a note of how the wire is secured to the frame how many rings, how to reupholster mustang seats. Basically, remove any rust with a wire brush and then spray paint the frame to make it look better and prevent future rust. The process for the upper seat back is essentially the same as for the lower with how to reupholster mustang seats few minor differences.

First, remove the back cover from the seat back by prying it off as shown to gain access to the inside. Just go around how to reupholster mustang seats seat back and pry at what is good agricultural practices location of the retaining clips.

The retaining rings alone hold the cover in place; the U-shaped wire in a sleeve is still used on the front side. Remove the old rings and note how many were used and where they were located. Note the folds also. The metal frame should how to reupholster mustang seats least be painted whether or not repairs are needed. Make sure the foam pads are properly adhering to the frame; apply some adhesive if they are not.

Cut new burlap for the lower seat frame and begin installing it using the paper-covered, curved wire as your guide. Try to duplicate the location and number of rings used based on what you saw when you took it out. Make sure you press down hard enough for the rings to grab the metal frame. You need special pliers for doing this, plus a little practice to get it right. After the burlap has been secured at the front frame and sides spray some adhesive around the round bar at the back.

Then gently stretch the burlap and roll it around the bar while pressing down, so the adhesive holds it in place. Trim any excess burlap and let the adhesive dry for a few minutes. To prevent the rings from being visible and making the seat bumpy and uncomfortable, they must be covered with padding.

This material is made from fabric scraps and is very inexpensive but still soft and easy to work with. Simply cut it into strips long enough to wrap around the seat frame and wide enough to overlap both sides by an inch or so.

Spray the padding and the burlap with adhesive before pressing it on and molding it to match the frame contours. The finished seat frame should look like this prior to being assembled with the seat bun. Note the padding extends all the way around the frame, all the way to the rear where the seat back will pivot. There is no need to cover the inner rings; the thickness of the bun will be enough to do so.

Liberally spray adhesive along the surface of the padding and where it makes contact with the bun and then assemble the finished seat frame and the bun together. There is no need to spray the center of the bun or the burlap in general. This can actually prevent proper movement of the various parts and how to reupholster mustang seats make future disassembly difficult. After the bun and frame have been assembled together, allow time for the adhesive to dry.

Then take the U-shaped wire rod you saved from the original seat cover and place what is the 9th and 10th amendment in the groove in the bun.

Use the bun as a guide to bend the rod back to the proper shape before inserting it into the designated sleeve in the new seat cover. Feeding the rod into the sleeve takes a fair amount of patience but it eventually goes in. Place the cover with the rod in it over the bun and begin installing the rings in the groove. Make sure the ring grabs both the wire rod and the underlying metal of the seat frame. Put the rings where you found them when you took the old cover off. Too many how to reupholster mustang seats are better than not enough.

To help make the seat a bit more comfortable and look better, it is a good idea to add a thin layer of extra foam along the top edge of the lower seat cushion. As with the padding used on the frame, cut a strip to size—long enough to wrap around the seat and wide enough to cover the outer cushion. Then spray the bun and the foam with adhesive before pressing the foam on the bun and molding it to shape. Excess foam can be squeezed together at the corners and trimmed as shown to remain even.

The first part of the new cover to be secured to the frame is the front edge. Then clamp the rings on at the proper locations so they grip the seat frame and the wire rods in the sleeves. This may take some effort and patience. Be careful not to overheat any areas by holding the gun too still or too close for too long. The idea is to stretch and remove wrinkles, not to melt anything.

To locate the holes for the installation of the circular bumpers, use an awl to poke a hole in the seat cover after dragging the point to find the right spot. Then use a razor blade or knife to make the hole large enough to clear the mounting bolts.

The hinge pin must be exposed, so cut the seat lower cover enough to allow it to poke through. Trim away all excess material such that the cover is even around the pin. The foam collar that how to change toolbar settings in chrome shaft for the seat back release lever is held in place with a small amount of spray adhesive.

The mechanism for the seat back release should also be lubricated with a small amount of spray-on lithium grease at the pressure points of movement. The seat back has a main bun like the lower seat frame and an upper foam piece on the back.

After spraying adhesive on the bun and the frame, place the bun on the steel frame.

Front Seat Refurbishment Step by Step

MUSTANG RESTORATION: FRONT SEAT REFURBISHMENT- STEP # Glue a piece of thinner foam to the rear foam cap, so the other extra foam is less obvious. Cut this piece to size and trim it in the same manner as the extra foam on the lower seat cushion. Give the adhesive time to dry here as well. MUSTANG RESTORATION: FRONT SEAT REFURBISHMENT- STEP # Feb 03,  · Insert your hand in between the foam and the upholstery and line up your hook and loop strips. Using one hand on the inside and one on the outside, slowly align these and fully seat these together. Now you can unroll the remaining fabric on the lower edge. Using a razor blade, make a small X shape on your stud and push this through. Reupholstering Mustang Seats - How To Reupholster ''86 Mustang Seats TMI Products' Seat Upholstery Kits Can Make Fox-Body Interiors Look New Again. Jim Smart. February 24,

Updating upholstery on any Mustang can really refresh the interior of your ride. Today we will show you the rear seat upholstery on this 04 GT coupe model.

We do want to note that these same steps can be used on all applications. Some of the coupes and convertibles can vary, but the general install will be about the same overall. Check out our YouTube channel for even more tech tips, installation videos, how-tos, and more.

The best place to go for anything Mustang related! Please use our Contact page for any inquiries or customer service needs. We will promptly respond as business hours return to our normal schedule on Monday, April 19th. Show More Show Less. Share this article! Reupholstery Steps Start by removing the rear seats from the car.

If you don't know how please check out our article explaining the steps to do so. Next, we will be removing the old upholstery from your foams. We also have an article that explains these removal steps. Unbox your new upholstery and check for any flaws or obvious defects. Our friends over at TMI were nice enough to send us a set of these 01 Bullitt style upholstery sets for our project. Take one of your new seat backs and roll the lower edge up a few times to make this install easier for you.

Once you have the lower edge rolled, start to slip this over the top edge of the foam. Be patient here, these are meant to be a tight fit so you may experience a little bit of repeated back and forth seating of the upholstery until you get it to where it should be.

Insert your hand in between the foam and the upholstery and line up your hook and loop strips. Using one hand on the inside and one on the outside, slowly align these and fully seat these together. Now you can unroll the remaining fabric on the lower edge. Using a razor blade, make a small X shape on your stud and push this through. Make sure to make small cuts here so you do not have an ugly mistake on your install. Moving to the other side, make another X cut for the bolt hole on this side.

Again, make small cuts until this is completely open for the hardware to pass through. Now you can hog ring your flaps down. Go ahead and load a new hog ring into your pliers. Pull the carpet and the fabric side as tight as possible and then you can hog ring these together. The J clip on the bottom will be next. This one can be a little tedious here so do not get discouraged. Pull the front and the back as tight as you can get it on each side.

Once you have any remaining slack out, start on one edge of the j clip and insert the male end into the female. Now that you have one edge started, you can slowly work your way down. Make sure to pull each side while seating the J clip to help remove any excess slack and wrinkles. The last step on the seat backs will be the latch trim. We noticed on our application that one of the trims had a slight defect and was a little tweaked. We used a heat gun to help make this a little more malleable and bent this one straight.

Set this one in place and pass both of the pull loops through their designated hole. Now you can install the 4 phillips head screws. Start by installing the listing rods into the new upholstery.

Using your hog ring pliers, install two hog rings on the rod to the foam. Space these out evenly on each side. You can go ahead and pull the fabric through the seat belt buckle area. Now you can secure the inner flaps together on these. Start on the inner edges first then move to the outer edges after and secure these with a few hog rings in each spot. Next, we can align and seat the hook and loop strips on each side. Take your time here and pull the upholstery tight to help alleviate any wrinkles when doing this.

Now we will start to go back in with new hog rings around the perimeter of the foam. I like to start in the center and alternate from side to side. This way you can slowly work out as many wrinkles while pulling the upholstery as tight as possible.

There is no specific pattern here really, you can go back with just the factory locations, but you can always add in more hog rings periodically if need be. Once you have all of the perimeter completed, flip the foam back over and you can try to work out any remaining wrinkles you may have. This is a great way to update and refresh the interior of your Mustang. This job should take you a solid afternoon to complete. When installing new upholstery we just want to stress to have a clean work surface and take your time.

This will involve a lot of tugging and pulling to make sure everything seats properly but the more time you take the better your final product will be. Start by removing the rear seats from the car. Check out the link in the description below. Check out the link in the description below to show you how this is done. Once you are happy with the top half, it is time to work on your lower edge.

Now you can install the four phillips head screws. Next we can align and seat the hook and loop strips on each side. Alright everyone, this is a great way to update and refresh the interior of your Mustang. When installing new upholstery I just want to stress to have a clean work surface and take your time. If you enjoyed this video, make sure to give us a thumbs up. Subscribe to our channel and make sure you have your notifications turned on so you can be up to date on all new tech content we release like this video.
